Continuous Flow Effluent Decontamination Systems

CONTINUOUS FLOW EDS

The Continuous Flow EDS is specifically designed for high flow and minimal solids. The high flow rate is designed to cope with short periods of high demand through the working day and/or known flow rates in short periods. Continous systems don’t normally come with large holding tanks, as once the system starts its sterilization and cooling it will continue to run until the flow of effluent has finished. The systems can run at high temperatures >140DegC for very short hold times. The system is designed to make the most of heat recovery and to be as efficient as possible.

Technical specifications

		Heating		Cooling
Flow (L/hr)	Holding tank (Litres)	Steam	Electric	Air	Water	BSL Category	Solids	Sterilizing temperature
100 L/hr	200 L					II/III	X	140°C for 1 minute
300 L/hr	200 L					II/III	X	140°C for 1 minute
500 L/hr	300 L					II/III	X	140°C for 1 minute
1000 L/hr	500 L			X		II/III	X	140°C for 1 minute

ASTELLBIO EDS QUESTIONNAIRE

Start planning your EDS system

Start now

Our AstellBio experts are waiting to assist you with your enquiry

Request quotation

ASTELL TOUCHSCREEN CONTROLLER

Digital process management with security and repeatability.

Astell supplies all its steam generators fitted with its unique PLC based touchscreen controller. It provides an easy-to-use interface for selecting and customising cycle data, changing machine parameters and reviewing the in-built archive capable of storing up to 5,000 previously run cycles. The touchscreen control module provides automatic operation and monitoring of the entire system, including data logs, alarms, and sensor information.
